Scorpius LED XTR 4500 QD – WideFlood

Scorpius LED XTR 4500 QD 24V 40W WideFlood

The Scorpius LED XTR 4500 QD – Wide Flood is designed for situations where a wide working area needs to be illuminated. This 24 V LED lamp combines high light dispersion with the innovative QUAKE Dampening system that absorbs and disperses vibrations. With an operational light output of approximately 4,200 lumens, this lamp delivers reliable performance in harsh conditions, above ground as well as underground. This version uses a “Wide Flood” lens for wide dispersion of light, unlike High Beam variants.

Why choose the Scorpius LED XTR 4500 QD?

• QUAKE Damping to dampen vibrations up to 20 Grms and minimize damage.
• Tempered glass lens that resists heat, abrasion, UV radiation and minerals/dust in harsh environments.
• 24 V-only version – simplifies inventory management and reduces theft risk
• Colored bezel (band around the lens) that helps recognize light pattern (Wide Flood vs. High Beam) during maintenance
• Rugged housing, high IP rating ( IP6K9K) for protection against dust and water.
• Good lumen per watt ratio, efficient use of energy.
• Does not interfere with other electronics thanks to very high EMC certification CISPR 25 class 5
• High CRI for color fidelity and pleasant light color for perfect working light
• Strong EMC protection for minimal electromagnetic interference
• 5-year warranty on light output and performance

Applications

• Earth movers, bulldozers, excavators
• Implements in heavier off-road environments
• Industrial applications with high dirt loads
• Tunneling, underground infrastructure
• Mining above and below ground
• Working areas near vehicles where wide exposure is desired

Warranty & certifications

• 5-year factory guarantees on light output
• EMC/standards: CISPR 25, EN12895, ISO 13766, ISO 14982, ISO 7637-2
• Salt spray test: 240 hours according to ISO 9227
• Temperature range: -40 °C to +85 °C with overheat protection
• IP6K9K rating (high pressure / steam cleaning resistant)
• Vibration/shock resistance: 20 Grms, 60 G shock tests

Additional info

• For intensive use in dusty / mineral environments, the tempered glass lens is more resistant to melting or distortion than plastic lenses
• The colored bezel helps technicians quickly identify which light pattern (Wide Flood / High Beam) is installed.
• Easy mounting / Mount the lamp securely with proper bolt (M10) and make sure the mounting angle is chosen to minimize glare.
• Cleaning / maintenance: tempered glass makes cleaning easier, and prevention of lens distortion at high temperatures
• Available from stock

Related Products
This work light is the replacement for the Scorpius N4401 QDOff-road vehicles (dump trucks, haulers)

• Scorpius LED XTR 4500 QD High Beam – for directional beam application
• Scorpius LED XTR 3500 QD Wide Flood / High Beam – for lighter applications
• Accessories: mounting brackets, cables
